CAST ON STRAP MACHINE

Features:


  • Produces One complete batteries per cycle from NS-40 to N-88 Battery
  • Produces 3 battery group per cycle for N-100 to N-200
  • Simple Functioning & Operator friendly Mechanism
  • Robust design to suit all climatic conditions in any part of the world
  • Minimum mould Changeover time


The system consist of two jig boxes /group holder such that ; When one jig box is being processed for casting , the other can be emptied & refilled with group element.


  • On loading the group stack in the jig box/group holder, the lug aligner mechanism automatically aliens the stacked element lugs, ensuring no lugs are left disturbed.
  • The jig box/ group holder is automatically turned upside down with the stacks, for further process.
  • The upside jig box / group holder carries the groups to :

  1.  Lug surface brushing station , where the lugs are cleaned for any dust etc. for proper fluxing
  2. Fluxing on lug for proper fusion / bonding
  3. The intercell connections are casted, which are of good quality and good consistency.
  4. The ready groups are carried back for removal and the second / other jig box is processed for COS operation.


The Unik (Formerly known as Shinghania Industries) COS moulds are designed for perfection, such that It gives long lasting life.


  • The robust design and state of art machining center facility enables, the cavities for straps and poles are highly accurate, which in turn saves lead of the esteemed customer
  • The moulds are designed in such way that the change -over time is minimal.
  • The heating & cooling of mould is well controlled & hence interruptions & rejection like half cast components, blow holes are arrested & rejection is negligible.
  • One Complete battery COS mould for battery variety.
  • For NS40 to N88 Battery variety & three for variety N100 to N200 battery groups.


TECHNICAL SPECIFICATIONS

CUSTOMER DATA REQUIRED:



1) Electrical input voltage & Frequency

2) Drawing & Sample Components like Pasted plates, groups, poles & straps etc to design the specific mould



UTILITIES TO BE PROVIDED BY

YOU AT SITE:


  1. Water Supply: Clean and Chilled Water (5˚C to 30 ˚C) for mould cooling, 30 – 40 LPM At mould inlet
  2. Air Supply: 6 bar constant
  3. Power Supply: 3 Phase 415 VAC With Neutral & Earthling
  4. Power Required: 50 KW
  5. Flux: 5 Litres



MACHINE SPECIFICATIONS & CAPABILITIES:



  1. Range of Production: NS - 40 to
    N-200
  2. Production cycle rate: 400 batteries / shift (depending upon the battery variety)
  3. Operators Required: Two skilled operators
  4. Cell group size to the max : Height: 223mm
  5. Width: 160mm (max size)
  6. Stack Thickness: 108mm (max size)
  7. Terminal Pole Height: 8 mm (max size)
  8. Machine Dimension:
  • Length: 2800 MM
  • Height: 2700 MM
  • Width: 2500 MM
  • Approx.Net Weight: 3 ton
  • Approx Gross Weight: 4 Tons





INBUILT UTILITIES:



  1. Lug Brushing Operation: 125 mm diameter wire brush driven by 0.5 HP motor
  2. Fluxing Operation: Automatic Lug Dipping. Capacity – 3 lires (Cos Flux Required)
  3. Control Panel: PLC interfaced with a color HMI
  4. Electrical Switchgears: Siemens and CE Equivalent
  5. Lead Pot Capacity: 1000 KG. Temp. Range: 30 ˚C to 500 ˚C
  6. Safety Measures: Metal Protection Guard. Electrical Interlocks.
